32 inch TV parts FHD tft open cell LCD panel V236BJ1-P01 LC390TA2A LSC550F13
Quick Details
Type:Projection
Place of Origin:China
Brand Name:OEM
Model Number:HV320WHB-N80 & HV320FHB-N80
Screen Size:32" - 100"
Use:Other
Display Format:1366x768 or 1920x1080
Wide Screen Support:Yes
Interface Type:DISPLAYPORT
Resolution:HD(1366*768), 1920*1080 or 1366*768
Receiving System:NTSC, PAL, SECAM
Product name:32" TFT LCD open cell with LVDS 30 pins Connector for TV 1366*768
Size:32 inch
Application:TV sets
Signal Interface:LVDS (1 ch, 8-bit) , 30 pins , 51pins Connector
Response Time:8 (Typ.)(G to G)
Input Voltage:12.0V (Typ.)
Cabinet Color:Black
Supply Ability
Supply Ability:1000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
1. Put EPE pad and panels into the box, 15pcs panels per box
2. Put the box on the pallet,8ea boxes per quarter pallet, a cover
on the top of the boxes
3. 16ea boxes and 2covers per pallet
4. Use wrapping film to bind up them
Port: FOB GUANGZHOU
Lead Time :within 5-7 workdays
Features
LVDS interface with 2 pixel / clock
High-speed response
Low color shift image quality
8-bit color depth, display 16.7M colors
High luminance and contrast ratio, low reflection and wide viewing
angle
DE (Data Enable) only mode
ADS technology is applied for high display quality
RoHS compliant
Application
Home Alone Multimedia TFT-LCD TV
Display Terminals for Control System
High Definition TV(HD or FHD TV)
TV application Products
we can supply other lcd open cell for you, such as below:
23.6" V236BJ1-P01
39" LC390TA2A
42" V420HJ2-P01
43" LC430EQY-SHM1
55" LSC550F13 or 17/19
55" LC550DUY-SHA1
| Parameter | Specification |
| Active area | 697.685(H)*392.256(V) mm |
| Number of pixels | 1920*1080 |
| Pixel pitch | 510.75(H) *RGB*510.75(V) |
| Pixel arrangement | Pixels RGB Vertical stripe |
| Display colors | 16.7M(8bits-true) |
| Display mode | Transmission mode, Normally Black |
| Open Cell Transmittance | 6.2 (typ.) % |
| Weight | 880 (typ.) gram |
| Power Consumption | 4.0 (typ.) Watt |
1.Payment term:
L/C,D/P,D/A,Western,Moneygram,the usual payment is paypal.T.T 30%
payment before production,the 70% balance should be paid shipment
after inspection.
2.Packing:
12 months warranty .lifetime maintainance.ROHS, CE & FCC
certificates in e-file format are available.1pc, sample order are
welcome for your evaluation.Pressure proof plastic bag and carton.
3.Shipping:
some products will be delivered by DHL.or tell us what do you want
to use the mode of transportation.
|
|
